Inlet wire blank

Φ0.018mm—Φ0.038mm

Outlet finished product

Φ0.012mm—Φ0.025mm

Maximum line speed

1200m/min (0.1—5kg capacity wind-up)

Maximum number of molds

12 (11+1)

Percent reduction

6% final: 5%

Wire drawing means

2 sets of tower wheels、2 capstans、spray sliding type

Cone pulley

Φ60×11section, 2 sets, constant speed pulley Φ60, 2 sets, sprayed ceramic cone pulley

Main engine

2.2KW, Y2-90L-2, Three-phase AC

Take-up motor

0.75KW, Servo, ISMH4-75B30CB-U234Z1 Platform Servo dynamo single phase alternating current

Traversing motor

0.4KW, 40B-30CB, Serve motor, single phase

Water pump dynamo

90W MP-55R, Single-phase alternating

Light

220V 40W, 220V 7W-11W Energy-saving lamp

Magnetic chock

24V 22W

Speed adjustment mode

Control multi-loop of small cabinet panel, speed adjustment by potentiometer

Traversing method

Silk rod drive moving, forward and reverse rotation of servo motor, max width at 160mm

Lubricating means

Downward-spray tower pulley, die frame self-spray (with water tank, water pump and pay-off rack)

Size (L x W x H)

1450 x1020 x1580mm

Weight

1.0T
