Description
https://www.parko-solar.com/PV-Panel-Connector-1500V-DC-CNC-Solid-Terminal.html
Model#: PK15-PC040B
Desc.: PV Panel Connector, 1500V DC, -CNC Solid Terminal
Products Main Features:
1. High voltage & current endurance capability; use for 1000V system;
2. Good impact resistance & ageing resistance capability; use imported
PPO raw material;
3. Lower contact resistance to 0.30 mΩ, contact material: pure
copper(99.9%);
4. Innovative seal & waterproof design,
5. High performance for ambient temperature range from -40℃ ～ +85℃, UV
resistance, insulation, suitable for long time outdoor use.
6. Good safety performance, TUV test & approved, sell well in Euro &
US.
7. Easy & quick for installation, high pull-out force, stable
self-locking structure, long working life above to 20 years.
8. Compatible with MC4, EVO2, QC4 etc. PV connectors.
Specification (Main Technical Parameters):
| Insulation material | Sabic PPO/PA | Safety degree | Class II |
| Rated current | 30A | Material RTI | 110℃ |
| Rated voltage | 1000V(TüV)/600V(UL) | Withdrawal force | ≥300N |
| Test voltage | 6KV(50Hz.1min) | Insertion force | ≤50N |
| Contact resistance | ≤0.5mΩ | Ambient temperature range | -40℃～+85℃ |
| Contact material | Copper.Tin plated | Suitable wire size range | 2.5mm²～6mm² (14～10AWG) |
| Water proof Degree | IP68(1m,1H) | Pin Dimension | ø4.0mm |
| Flame class | UL94-V0 | Standard | TUV IEC 62852 |
Specification (Main Technical Parameters):
Product Application Diagram:
